Also known as:
-
Leaded Glass
-
Radiation Protective Glass
-
Lead Glass Panel
-
X-ray Protective Window
-
Lead Viewing Glass
📊 Technical Specifications
| Feature | Details |
|---|---|
| Lead Equivalence | From 1.0 mmPb to 3.0 mmPb (Complies with ASTM / IEC 61331) |
| Light Transmission | 85–90%, varies by thickness |
| Density | ~4.36 g/cm³ |
| Standard Thickness | 6 mm, 8 mm, 10 mm, 12 mm, 15 mm, 18 mm |
| Panel Size Options | 8″×10″, 12″×16″, 24″×30″, 36″×72″, customized sizes available |
| Color Tint | Natural amber or pale yellow hue |
| Finish Type | Polished or ground edges; optional safety corners |
| Fire Rating | Non-flammable, suitable for integration into fire-rated assemblies |
| Certifications | IEC 61331, ASTM C1036, EN 61331-2, NCRP 147 |
🏥 Key Applications
| Sector | Typical Use Case |
|---|---|
| Medical Imaging Centers | X-ray and CT control room viewing panels |
| Dental & Veterinary Units | Small shielded windows in exam or scan rooms |
| Industrial Testing Labs | Radiographic inspection room panels |
| Nuclear Research Facilities | Radiation-safe observation through gloveboxes and hot cells |
| Security & Customs Areas | Shielded inspection panels in scanner rooms |
| Cleanrooms & Pharmacies | Visual control panels with radiation shielding |
⚙️ Optional Features & Customization
| Custom Feature | Available Options |
|---|---|
| Lamination | Dual-layer for added impact resistance |
| Framing Kits | Aluminum, steel, or lead-lined wooden frames |
| Pre-Fabricated Assemblies | Glass pre-installed in doors, partitions, or shielding panels |
| Privacy Features | Sandblasted zones, blackout borders, full frosting available |
| Size & Shape Customization | Laser-cut, drilled, or CNC-ed to specification |
🚛 Logistics & Installation
| Aspect | Specification |
|---|---|
| Installation Types | Flush-mounted, overlapped, or framed |
| Packaging | Wooden crates with internal foam and film protection |
| Handling Recommendations | Use gloves and avoid hard contact; product is dense and brittle |
| Documentation Support | CAD drawings, cut sheets, and installation guides available |
| Export Capability | Global shipping with customs and compliance assistance |
✅ Why Choose Risdom Tech
-
Strict compliance with global radiation safety standards
-
Flexible size and lead equivalency options
-
Quick production for standard sizes
-
Full support with technical drawings and OEM needs
-
Experience with hospitals, NDT sites, and scientific labs worldwide
📩 Request a Quote
Email: 4118@88.com
CAD Drawings & Tech Sheets: Available upon request
Lead Time: 7–14 days typical for standard panels
Shipping: Worldwide
MOQ: Based on project size or panel quantity
