Also referred to as:
-
Lead-lined radiation doors
-
Shielded X-ray room doors
-
Radiation-safe sliding doors
-
Lead core swing doors
-
Medical radiation shielding doors
📐 Technical Specifications
| Component | Details |
|---|---|
| Door Type | Swinging (single/double leaf), Sliding (manual or automatic) |
| Core Material | Solid core with integrated lead sheet |
| Lead Thickness | 1/32” (0.8 mm) to 1/4” (6.35 mm), customizable based on shielding needs |
| Door Skin Options | Stainless steel, HPL (High-Pressure Laminate), powder-coated steel |
| Frame Material | Galvanized steel, stainless steel, or aluminum |
| Radiation Shielding Level | Up to 3 mm Pb equivalent or more, per project specifications |
| Standard Sizes | 900 × 2100 mm, 1000 × 2200 mm, or custom sizes available |
| Weight (Est.) | Varies with lead thickness; ~40–80 kg/m² |
| Fire Rating | Optional fire-rated versions available (30 to 90 minutes) |
| Accessories | Vision panels (lead glass), automatic closers, anti-pinch handles |
| Compliance | Follows NCRP, ASTM, and local radiation safety regulations |
🏥 Applications by Industry
| Sector | Application |
|---|---|
| Healthcare | CT scan rooms, fluoroscopy rooms, X-ray suites, PET/MRI shielding |
| Veterinary Clinics | Imaging and diagnostic rooms requiring radiation protection |
| Nuclear Facilities | Operator room access points, shielded observation areas |
| Industrial Inspection | NDT (Non-destructive Testing) rooms with radiation exposure |
| Research Labs | Entryways to radiation-controlled zones and testing chambers |
🔧 Customization Options
| Feature | Options |
|---|---|
| Opening Direction | Left-hand / Right-hand swing; left/right automatic sliding |
| Vision Window | Optional, fitted with X-ray lead glass (same Pb equivalent as door) |
| Surface Finish | Brushed stainless, powder-coated, wood grain laminate |
| Lead Lining | Full door height or partial (as required) |
| Door Frame Types | Welded or knock-down frames |
| Automation | Sliding doors available with electric automation for hospital environments |
| Seals & Gasketing | Optional radiation-safe perimeter sealing for enhanced protection |
🚚 Logistics & Packaging
| Aspect | Details |
|---|---|
| Packing Method | Palletized, foam-wrapped, corner-protected, export-grade wooden crates |
| Installation Instructions | Provided with each order; remote technical support available |
| Lead Time | 10–15 days for standard; 20–25 days for custom automation or bulk orders |
| Documentation | Includes MSDS, conformity certificate, CAD drawings, radiation test report |
| Export Support | Worldwide delivery with standard export documents and insurance |
✅ Why Choose Risdom Tech
-
Engineered to Fit: Every door is tailored to your shielding requirement and room layout.
-
Certified Safety: Built with materials compliant with global radiation safety regulations.
-
Custom Aesthetics: Choose from a wide range of finishes to match hospital or lab interiors.
-
Quiet & Smooth Operation: Especially important in clinical environments.
-
Reliable Logistics: On-time shipping and professional packaging ensure secure delivery.
